Real Range Estimation between 490 – 925 km
City – Cold Weather * 615 km
Highway – Cold Weather * 490 km
Combined – Cold Weather * 555 km
City – Mild Weather * 925 km
Highway – Mild Weather * 640 km
Combined – Mild Weather * 765 km
Long Distance Suitability
First Leg Distance 499 km
Charging Stop 0km
Second Leg Distance 264 km
Total Distance 763 km
First Leg Duration 4h 32min
Charging Stop 15 min
Second Leg Duration 2h 24min
Total Duration 7h 11min
Battery
Nominal Capacity * 114.0 kWh
Battery Type Lithium-ion
Number of Cells 6600
Architecture 800 V
Warranty Period 8 years
Warranty Mileage 160,000 km
Useable Capacity* 112.0 kWh
Cathode Material No Data
Pack Configuration 220s30p
Nominal Voltage 800 V
Form Factor Cylindrical
Name / Reference Samsung 48X
Charging
Home / Destination
Charge Port Type 2
Port Location Left Side – Front
Charge Power 22 kW AC
Charge Time (0->665 km) 6 hours
Charge Speed 110 km/h
Fast Charging
Charge Port CCS
Port Location Left Side – Front
Charge Power (max) 253 kW DC
Charge Power (10-80%) 184 kW DC
Charge Time (66->532 km) 27 min
Charge Speed 1030 km/h
Autocharge Supported No
Plug & Charge
Plug & Charge Supported Yes
Supported Protocol ISO 15118-2
Battery Preconditioning
Preconditioning Possible Yes
Automatically using Navigation No
Performance
Acceleration 0 – 100 km/h 3.0 sec
Top Speed 270 km/h
Electric Range * 665 km
Total Power 597 kW (812 PS)
Total Torque 1200 Nm
Drive AWD
